| ELECTRIC FIELD |
EF-Detection
(Non-Contact Voltage) |
 |
| INTELLIGENT |
Auto Power Off |
|
| LINE-VOLTAGE HZ |
With 3 Trigger Levels
(V Position) |
|
| STANDARD |
Hi-Z DCV & ACV
6V To 600V, 3 Ranges |
|
| DIODE TEST |
Yes |
|
| AUDIBLE CONTINUITY |
Yes |
|
| OHMS |
600Ω Range |
|
| MICRO-AMPS AC/DC |
400.0μA To 2000μA
For Flame Sensors |
|
| EMC |
Meets EN61326:2013 |
|
| TRANSIENT PROTECTION |
Up To 4kV 1.2/50μs
Lightning Surge |
|
| INPUT PROTECTION |
600V On All Functions |
|
| LVD |
Meets EN61010-1/-2-030/-2-033
CAT III 300V & CAT II 600V |
|
| FUNCTION SELECTOR |
Yes |
|
| HOUSING MATERIAL |
Fire-Retarded, UL Listed |
|
| FREQUENCY |
10Hz To 30kHz
(Auto-VΩ Position) |
|
| CAPACITANCE |
100nF To 2000μF,
5 Ranges |
|
| AUTOCHECK OHMS |
6kΩ To 6MΩ,
4 Ranges |
|
| AUTOCHECK |
Lo-Z DCV & ACV
6V To 600V, 3 Ranges |
|
| AUTOCHECK FEATURE |
Automatic DCV, ACV
& OHMS Selection |
|
| DATA MEASUREMENT |
5/Sec Fast |
|
| LARGE EASY TO READ LCD DISPLAY |
6,000 Counts |
|
| FULLY AUTO-RANGING |
Yes |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
