| 12mm SLIM-PROBE OPEN JAWS |
Slide-in to Measure; Easy Access to
Tight Electrical Box Wirings |
 |
| CREST MaxMin IN-RUSH CURRENTS |
Fast Captures In-rush +/- Peak
Signals at Durations as Short as
5ms; Automatic APO Disable
Feature |
|
| INNOVATIVE BeepLit™ DIODE TEST |
Short-Beep Alerts on Forward Voltages
<0.85V; Continuous Beep & Backlight
Effects for Shorted Diodes |
|
| REC MaxMin DISPLAY READINGS |
Records Max & Min Readings Over
Time; Automatic APO Disable
Feature |
|
| RELATIVE ZERO |
REL for Convenient Readings
Comparison |
|
| DATA HOLD |
Freezes the Displaying Reading for Later View |
|
| DCμA |
For HVAC Flame Sensors Testing Via
Test Probes |
|
| TYPE-K TEMPERATURE |
Selectable °C and °F Readings; Comes with a Bkp60 Bead Probe |
|
| CAPACITANCE |
2 Auto-ranges up to 2500μF to
Measure Motor Capacitors |
|
| INNOVATIVE BeepLit™ CONTINUITY |
Quick Open-short Tests on Switches and Wires; Beep & Backlight Effects for Noisy Environments |
|
| RESISTANCE |
Best Resolution 0.1Ω At 600Ω Range.
5 Auto-ranges Up To 6000kΩ |
|
| TRANSIENT PROTECTION |
Up To 6kV 1.2/50μs Lightning Surge; Fully Certified by Independent Test Lab; Years of Credibility for Serious Users |
|
| DUAL SENSITIVITIES EF-DETECTION |
Features Non-Contact (NCV) & Single-Probe Voltage Detections for Identifying Live Lines; Added User Selectable Hi/Lo Sensitivities |
|
| 12.5mm ACA FORK-CLAMP |
Measures AC 200Amps for Conductor
size Up To 12.5mm |
|
| LVD CAT III 600V & CAT IV 300V |
Certified EN61010-2-032, EN61010-2-033, EN61010-1 & Relevant Standards on CAT III 600V & CAT IV 300V |
|
| 1.0% DCV BASIC ACCURACY |
Measures Up To 600V DC |
|
| DIRECT LPF ACV & LPF Hz FOR VFDs |
Measures Voltage & Frequency of Most Variable Frequency Drives and Noisy Electrical Signals up to 600V AC |
|
| BACKLIGHTED LCD DISPLAY |
For Easy Viewing in The Dark; 10 mins Auto-Off; Disable Option |
|
| FULLY AUTO-RANGING |
Shortens the Time to Measure and
Increases the Ease of Use |
|
| INTELLIGENT AUTO-POWER-OFF (APO) |
Stays ON While in Measurements;
Intelligently Turns OFF to Extend Battery Life; Disable Option |
|
| ERGONOMIC & STREAMLINE BODY |
Body width <50mm Fits Nicely in One
Hand; Overall Length <200mm For Easy Carrying |
|
| TRUE RMS MEASUREMENTS |
For Non-sinusoidal & Complex
Waveforms of Voltages & Currents |
|
| RUGGED & DURABLE |
Robust Enclosure; Precise & Reliable
Rotary Switch; Premium Plating & Low
Leakage PCB |
|
| EMC |
Superior Immunity to Interferences;
Reliable Operations and Readings; Meets EN61326-1 |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
