| AC-DETECTION SHAKER |
The Shaker Signals That Significant ACV Is Being Measured |
 |
| AUTOMATIC DCV, ACV & CONTINUITY SELECTION |
Shortens The Time To Test And Increases The Ease Of Use |
|
| INTELLIGENT AUTO ON & OFF |
Automatic Power On & Power Off To Extend Battery Life |
|
| SCREW-ON STATIONARY (RED) PROBE BODY |
Screw-On Design For Easy User Replacement |
|
| DETACHABLE(BLACK) TEST LEAD |
Standard 4mm Plug Design For Easy User Replacement |
|
| 19mm PROBE PITCH |
For European Receptacle Testing |
|
| IP2X 4mm TIPS DETACHABLE PROBES |
Spring Retractable Shrouded 4mm TIPS For IEC61010 + IEC61243-3 Ed. 3 Version; Optional 2mm+CAP/4mm For Mere IEC61010 |
|
| EMC |
Meets EN61326-1:2013 |
|
| RST PHASE SEQUENCE INDICATION |
Convenient Phase Rotation Testing By Using Only Two Poles |
|
| BACKLIT LCD & FLASH-LIGHT |
For More Precise Indication & Easy Viewing In The Dark |
|
| EF-DETECTION |
Both Non-Contact & Single-Probe Voltage Detection For Identifying Live Lines And Thus The Polarity |
|
| ERGONOMIC STREAMLINE DESIGN |
Fits Comfortably In One's Hand |
|
| UP TO 1kV VOLTAGE TESTING |
Improved Testing Capabilities |
|
| DOUBLE INJECTION HOUSING |
Seamless Over-Molded Push-Button Switches And LED / LCD Display Windows For Harsh Environments |
|
| DC AND AC INDICATIONS |
+V Lights Up For Correct DC Polarity, -V Lights Up For Reversed DC Polarity Both +V & -V Light Up For AC Indication |
|
| TRANSIENT PROTECTION |
Up To 8kV 1.2/50μs Lightning Surge; Superb Protection For Serious Users |
|
| LVD CAT III & CAT IV SAFETY |
Meets EN61010 And EN61243-3 ED. 3, To CAT III 1000V & CAT IV 600V |
|
| BATTERY-LESS VOLTAGE DETECTION |
LEDs Indicate The Presence Of Voltages With Power Supplied By The Test Object, Without The Need Of Battery Power |
|
| ELV LIMIT INDICATION (BATTERY-LESS) |
The LED Indicates The Presence Of A Voltage Beyond The ELV Limit (120 VDC/50 VAC) With Power Supplied By The Test Object, Without The Need Of Battery Power |
|
| AUDIBLE CONTINUITY |
For Quick Open-Short Tests On Switches, Fuses, And Wires |
|
| LEAKAGE LOAD FOR RCD |
Internal Leakage Load Provided. Typical Leakage Current 30mA At 230V (USA GFCI Version Also Available) |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
