| HIGH ACCURACY |
0.02% Basic DCV Accuracy;
1μVDC Best Resolution |
 |
| ANALOG BAR-GRAPH |
Fast Update Rate 60/Sec |
|
| LARGE 500,000 Counts LCD Display |
5/Sec Fast Nominal Update Rate |
|
| ASIC TECHNOLOGY |
More Functions & Features
At Affordable Prices |
|
| DUAL DIGITAL DISPLAY |
Simultaneously View Relevant
Parameters In Complementary Display |
|
| T1-T2 TYPE-K TEMPERATURE |
2 Channel Measurements,
Selectable °C & °F Readings |
|
| DIODE TEST |
For Checking Diodes
And Rectifiers |
|
| DATA HOLD |
Freezes The Displaying
Reading For Later View |
|
| MAX MIN AVG RECORD |
Record Max, Min & AVG
Readings; Auto-Ranging |
|
| nS CONDUCTANCE |
nS=1/GΩ Virtually Extends
Resistance Measurement To
The Order Of GΩ. It Is Useful
For Leakage Measurements |
|
| FAST AUDIBLE CONTINUITY |
For Quick Open-Short Tests
On Switches, Fuses, And Wires |
|
| %4-20mA LOOP CURRENT |
For Process Control |
|
| X-SPEED CAPACITANCE |
X-Speed Measures Up To 25mF
Only In A Few Seconds; 1kV Protection |
|
| CURRENT & Hz |
Measures Current & Frequencies,
AC & DC In Dual Display |
|
| ERGONOMIC STREAMLINE DESIGN |
Fits Comfortably In One's Hand |
|
| TRANSIENT PROTECTION |
Up To 12kV 1.2/50μs Lightning Surge;
Superb Protection For Serious Users |
|
| EMC |
Meets EN61326-1:2013 |
|
| LVD SAFETY |
Meets EN61010-1 ED. 3.0,
EN61010-2-030 ED. 1.0 &
EN61010-2-033 ED. 1.0 To
CAT IV 1kV |
|
| PROTECTIVE HOLSTER |
With Holders For Probe Storage
And "Third Hand" Feature,
Replaceable & Washable |
|
| AC, AC+DC 100kHz TRUE RMS |
For Non-Sinusoidal Waveforms
Of Complex Voltage Or Current Signals |
|
| INTELLIGENT AUTO-POWER-OFF |
To Extend Battery Life. I-APO Resets On
Significant Operation & Measurements |
|
| BEEP-JACK AUDIBLE & VISIBLE WARNING |
Guards Against Improper Current Terminals
Plug In. Decreases Risks Of Damage |
|
| PC INTERFACE CAPABILITY |
Optional Purchase USB Cable
With Data Recording PC Software
For Win7/8/10 |
|
| VFD V & Hz FEATURE |
Measures Fundamental
Voltage & Frequency Of Most
Variable Frequency Drives |
|
| dBm FUNCTION |
With 20 Selectable
Reference Impedance Values |
|
| Hz OF LINE LEVEL VOLTAGE |
Measures Noisy High Voltage
ACV Frequencies Up To 200kHz
In Dual Display |
|
| HIGH IMPEDANCE VOLTAGE |
1000VAC/DC Measuring Capabilities;
High Input Impedance For
Load Sensitive Circuits |
|
| LOGIC LEVEL Hz |
Measures Digital Logic Level
Frequencies Up To 1MHz |
|
| LOGIC LEVEL DUTY% |
Measures Digital Logic Level
Duty Cycle % Readings |
|
| CREST (PEAK HOLD) |
Captures Instantaneous
+Peak & -Peak, Auto-Ranging |
|
| FUNCTION SELECTION |
Toggle Conveniently Between
Primary & Secondary Functions |
|
| PAPER-WHITE DISPLAY BACKLIGHT |
For Easy Viewing In The Dark |
|
| AUTO & MANUAL-RANGING |
Auto-Ranging With
Manual-Ranging Override |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
