| FULLY AUTORANGING |
Shortens The Time To Measure
And Increases The Ease Of Use |
 |
| PC INTERFACE CAPABILITY |
Optional Purchase RS232C+USB Cables
With Data Recording PC Software
For Win7/8/10 |
|
| 0.03% HIGH BASIC ACCURACY |
With Large Easy To Read Display |
|
| INTELLIGENT AUTO POWER OFF |
To Extend Battery Life |
|
| FAST MEASUREMENTS |
Data 5 Times / Sec
Bar-Graph 60 Times / Sec |
|
| RELATIVE ZERO MODE |
For Convenient Readings
Comparison & Offset |
|
| HIGH RESOLUTION MODE |
999,999 Counts In Hz
500,000 Counts In DCV |
|
| HIGH VOLTAGE Hz |
For Noisy Electrical Signals |
|
| DATA HOLD |
Freezes The Displaying
Reading For Later View |
|
| %4-20mA LOOP CURRENT |
For Process Control |
|
| DIODE TEST |
For Testing Diodes And Rectifiers |
|
| CAPACITANCE |
Auto-Ranging Up To 9999μF With
1000V Protection |
|
| AUDIBLE CONTINUITY |
For Quick Open-Short Tests
On Switches, Fuses, And Wires |
|
| EMC |
Meets EN61326:2013 |
|
| TRANSIENT PROTECTION |
Up To 8kV 1.2/50μs Lightning Surge,
More Confidence For Serious Users |
|
| LVD |
Meets EN61010-1/-2-030/-2-033
CAT III 1kV & CAT IV 600V |
|
| DC+AC TRUE RMS |
20kHz Voltage Bandwidth To
Measures Signal True Value
Regardless Of Waveforms |
|
| PROTECTIVE HOLSTER |
Increases Product Durability.
Replaceable & Washable |
|
| HBC FUSE PROTECTED |
High Breaking Capacity
1000V Ceramic Fuse Protected |
|
| FIRE RETARDED CASE |
For Reinforced Safety |
|
| INPUT WARNING |
Audible And Visible Warning
Against Improper Plug In |
|
| 1kV AC VOLTAGE MEASUREMENT |
Improved Measuring Capabilities |
|
| dBm FUNCTION |
With 20 Selectable
Impedance Values |
|
| DIGITAL SIGNAL Hz |
For Logic Level Signal
High Frequency Measurements |
|
| RANGE |
Autoranging With Manual-
Ranging Override |
|
| LAST SET FUNCTION DEFAULT |
Last Set Function Will Be Saved As
Power-Up Default For Ease Of Use |
|
| BACKLIGHTED LCD DISPLAY |
For Easy Viewing In The Dark |
|
| MAX-MIN RECORD |
Record Max, Min, Max-Min
Readings, Autoranging |
|
| CREST (PEAK HOLD) |
Captures Instantaneous Peak
Readings As Short As 0.8ms In Duration |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
