| ASIC TECHNOLOGY |
More Functions & Features
At Affordable Prices |
 |
| LARGE 6000 COUNTS LCD DISPLAY |
5/Sec Fast Nominal Updata Rate |
|
| HIGH ACCURACY |
0.2% Basic DCV Accuracy |
|
| ANALOG BAR-GRAPH |
Fast Update Rate 40/Sec |
|
| LOGIC LEVEL Hz (mV FUNCTION) |
Measures Hi Frequency
Logic Signals |
|
| LINE LEVEL Hz (V FUNCTION) |
Measures Noisy High Voltage
ACV Frequencies |
|
| EF-DETECTION |
Both Non-Contact (NCV) &
Single-Probe Voltage Detection
For Identifying Live Lines |
|
| DATA HOLD |
Freezes The Displaying
Reading For Later View |
|
| TYPE-K TEMPERATURE |
Selectable °C & °F Readings |
|
| AUTO-POWER-OFF |
To Extend Battery Life |
|
| ERGONOMIC STREAMLINE DESIGN |
Fits Comfortably In One's Hand |
|
| TRANSIENT PROTECTION |
Up To 6kV 1.2/50μs Lightning Surge;
Superb Protection For Serious Users |
|
| EMC |
Meets EN61326-1:2013 |
|
| LVD SAFETY |
Meets EN61010-1/-2-030/-2-033
CAT II 1kV, CAT III 600V & CAT IV 300V |
|
| RUGGED & DURABLE |
High-Impact Fire-Retarded Enclosure
For Reinforced Safety & Durability |
|
| PC INTERFACE CAPABILITY |
Optional Purchase RS232C+USB Cables
With DATA Recording PC Software
For Win7/8/10 |
|
| PROTECTIVE HOLSTER |
With Holders For Probe Storage
And "Third Hand" Feature
Replaceble & Washable |
|
| BEEP-JACK AUDIBLE WARNING |
Beeps Against Improper A-Terminal
Plug In. Decreases Risks Of Damage |
|
| FAST AUDIBLE CONTINUITY |
For Quick Open-Short Tests
On Switches, Fuses, And Wires |
|
| DIODE TEST |
For Checking Diodes & Rectifiers |
|
| HIGH IMPEDANCE VOLTAGE |
1000VAC/DC Measuring Capabilities;
High Input Impedance For
Load Sensitive Circuits |
|
| CAPACITANCE |
Up To 3000μF With 600V Protection;
Auto-Ranging |
|
| FUNCTION SELECTION |
Toggle Conveniently Between
Primary & Secondary Functions |
|
| AUTO & MANUAL-RANGING |
Auto-Ranging With
Manual-Ranging Override |
|
| HIGH SPEED AUTO-RANGING |
Shortens The Time To Test
And Increases The Ease Of Use |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
