| RUGGED & DURABLE |
High-Impact Fire-Retarded
Enclosure With Battery
Compartment & Access Door |
 |
| DIODE TEST |
For Testing Diodes & Rectifiers |
|
| CAPACITANCE |
6 Auto-Ranges Up To 2000μF
To Measure Motor Capacitors |
|
| AUTO-POWER-OFF |
Extends Battery Life |
|
| DATA HOLD |
Freezes The Displaying
Reading For Later View |
|
| 5ms CREST-MAX |
Captures In-Rush Peak Signals Of ACA Or ACV As Short As 5ms In Duration |
|
| HIGH CURRENT (ACA) Hz |
Measures Non-Invasive
ACA Frequency VIA Clamp Jaws |
|
| HIGH VOLTAGE (ACV) Hz |
Measures Noisy High Voltage
ACV Frequency VIA Test Leads |
|
| 0.5% DCV BASIC ACCURACY |
DCV 4 Auto-Ranges To 1000V;
ACV 4 Auto-Ranges To 1000V |
|
| EF-DETECTION |
Both Non-Contact (NCV) &
Single-Probe Voltage Detection
For Identifying Live Lines |
|
| RELATIVE ZERO MODE |
For Convenient Readings
Comparison & Offset |
|
| TRANSIENT PROTECTION |
Up To 12kV 1.2/50μs Lightning Surge;
More Confidence For Serious Users |
|
| PC-COMM INTERFACE CAPABILITY |
Optional Purchase RS232C+USB Cables
With Data Recording PC Software
For Win98/NT4/2K/XP/Vista/Win7 |
|
| EMC |
Meets EN61326-1:2006 (EN55022,
EN61000-3-2/-3 & EN61000-4-2/-3/-4/-5/-6/-8/-11) |
|
| GHOST-VOLTAGE-BUSTER |
LoZ Drains Ghost/ Stray Voltages
Leaving Only Hard Signals
On Meter Readings |
|
| FULLY AUTO-RANGING DMM |
Shortens The Time To Measure
And Increases The Ease Of Use |
|
| AUTOCHECK FEATURE |
Automatic Selection Of
LoZ DCV, LoZ ACV & OHMS |
|
| VFD V & Hz FEATURE |
Measures Fundamental
Voltage & Frequency Of Most
Variable Frequency Drives |
|
| ERGONOMIC & STREAMLINE BODY |
Also Comes With A Soft Pouch
For Easy Carrying & Protection |
|
| RESISTANCE |
6 Auto-Ranges Up To 40MΩ |
|
| LVD CAT IV 1000V SAFETY |
Meets EN61010-2-032, EN61010-1
& UL Standards On CAT IV 1000V |
|
| FAST AUDIBLE CONTINUITY |
For Quick Open-Short Tests
On Switches, Fuses, And Wires |
|
| LARGE HALL-EFFECT CLAMP JAWS |
For Large Conductors Up To 55mm
With DC & AC 2000A Capability |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
