| DATA HOLD |
Freezes The Displaying
Reading For Later Viewing |
 |
| BATTERY COMPARTMENT |
With Access Door For
Easy Battery Replacement |
|
| PROBE HOLDERS |
Built-In Probe Storage Holders |
|
| ELECTRIC FIELD EF-DETECTION |
Features Both Non-Contact &
Probe Contact EF-Detection
For Tracing Live Wiring |
|
| AUTOCHECK FEATURE |
Automatic Selection Of
LoZ DCV, LoZ ACV & OHMS |
|
| GHOST-VOLTAGE-BUSTER |
LoZ Drains Ghost/Stray Voltages
Leaving Only Hard Signals
On Meter Readings |
|
| AUTOCHECK-RESISTANCE |
4 Ranges; Auto-Ranging Up To 6 MΩ |
|
| CAPACITANCE |
5 Ranges; Auto-Ranging
Up To 2000μF With 600V Protection |
|
| DIODE TEST |
For Testing Diodes And Rectifiers |
|
| 600 OHMS RANGE WITH AUDIBLE CONTINUITY |
For Low Resistance & Quick Open-Short
Tests On Switches, Fuses, And Wires |
|
| TRANSIENT PROTECTION |
Up To 6.5kV 1.2/50μs Lightning Surge;
More Confidence For Serious Users |
|
| EMC |
Meets EN61326(1997, 1998/A1),
EN61000-4-2(1995), & EN61000-4-3(1996) |
|
| UP TO AC 2000 AMPS MEASUREMENTS |
2 Non-Invasive AC Current Auto-Ranges
VIA Clamp Jaws; Best Resolution 0.1A |
|
| HIGH VOLTAGE Hz |
Measures Noisy High Voltage
ACV Frequencies VIA Test Leads |
|
| HIGH IMPEDANCE VOLTAGE |
600VAC/DC Measuring Capabilities;
High Input Impedance For
Load Sensitive Circuits |
|
| DISPLAY BACKLIGHT |
For Easy Viewing In The Dark |
|
| TRUE RMS MEASUREMENTS |
For Non-Sinusoidal Waveforms
Of AC Voltages & AC Currents |
|
| 0.5% DCV BASIC ACCURACY |
3 Ranges; Auto-Ranging
Up To 600 Volts, 0.1V Resolution |
|
| LVD CAT III 600V SAFETY |
Meets EN61010-2-032 CAT III 600V |
|
| RUGGED & DURABLE |
High-Impact Fire-Retarded Enclosure
For Reinforced Safety & Reliability |
|
| LARGE U-SHAPE CLAMP JAWS |
Measure ACA Of Large Single Conductor
Or Differential ACA Of Multiple Conductors |
|
| EF ANTENNA |
Conveniently Located At The Jaw Tip
For Non-Contact EF-Detection (NCV) |
|
| STYLISH & HANDY |
Also Comes With A Soft Pouch
For Easy Carrying & Protection |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
