| Direct Use on Lives |
Apply to and Removal from Hazardous
Live Uninsulated Conductors Permitted |
 |
| Large 51mm AmpTip® Jaws |
Easy Measure on Both Large and
Slim Conductors |
|
| Type-K Temperature |
Measures from -40.0 °C to 400.0 °C or
-40.0 °F to 752.0 °F, Selectable |
|
| Capacitance |
Measures Start & Run Motor
Capacitors from 10.0µF to 999.9µF |
|
| Resistance |
2 Ranges @ 600.0Ω and 6.000kΩ |
|
| Fast Beeplit™ Continuity |
Quick Open-short Tests with Backlight
Effects on Switches, Fuses, and Wires |
|
| High Accuracy 0.5% DCV |
2 Ranges @ 60.00V and 999.9V |
|
| Direct LPF ACV |
For Noisy Electrical and VFD Signals;
2 Ranges @ 60.00V and 999.9V |
|
| Diode Test |
Quick Checks on Diodes and Rectifiers |
|
| High Bandwidth AC+DCV |
Range @ 999.9V; Bandwidth up to 3kHz |
|
| AmpTip® Current |
Measures at Jaw Tip for Small-sized
Thin Conductors up to 40.00A |
|
| Regular Current |
Measures at Jaws Center for
Regular Conductors up to 999.9A |
|
| Clamp-on Hz |
Measures Non-Invasive Current
Frequency Via Clamp Jaws; 40Hz to 70Hz |
|
| AC Line-Level Hz |
Measures Noisy High Voltage
Frequency via Test leads; 40Hz to 70Hz |
|
| EF-Detection |
Both Non-Contact (NCV) & Single-Probe
Voltage Detection for Identifying Live Lines |
|
| Convenient Dual Display |
Volt/Amp+THD%, Volt/Amp+DF%,
(AC)VA/W/VAR+PF, and (AC+DC)VA+DCA |
|
| REC MAX/MIN |
Compares and Records
Extreme Display Readings |
|
| THD% of Volt/Amp Functions |
Harmonic Distortion of Total or
Individual Harmonics up to the 25th |
|
| DF% of Volt/Amp Functions |
Distortion Factor of Total or
Individual Harmonics up to the 25th |
|
| LVD with UL Listed |
Power analysis Applications for
CAT III 1kV & CAT IV 600V Areas |
|
| AC+DC Power VA |
Measures Power VA in AC+DC
mode with Dual Display DCA |
|
| Single-phase & 3-phase Balanced-load Power |
Measures AC Power W, VA, and
VAR with Dual Display PF |
|
| Relative Zero Mode |
Convenient Readings
Comparison & Offset |
|
| DC-Zero Mode |
Offsets DCA residuals from magnetic
hysteresis of the jaws |
|
| 3-phase Unbalanced-load Power |
Measures and Calculates 3-wire/ 4-wire
system Power W cost-effectively |
|
| AC, AC+DC TRMS |
Ideal for Non-sinusoidal Waveforms on
Voltage, Current, Harmonics, and Power |
|
| Rugged & Durable |
Robust Fire-retarded Housing with
Battery Access Door |
|
| Ergonomic & Streamlined Body |
Fits Nicely in A Hand with Single-Handed Rotary Switch Operation |
|
| Data HOLD |
Freezes the Displaying Reading
for Later Viewing |
|
| Fully Auto-ranging |
Shortens the Time to Measure and
Increases the Ease of Use |
|
| Auto Power Off |
Turns Off Automatically to
Extend Battery Life |
|
| Transient Protection |
8kV 1.2/50µS Lightning or Switching
Surge Protection for Serious Users |
|
| 1kV Input Protection |
Superb Protection for Misinput on
All Functions and Ranges |
|
| Back-lighted LCD plus Working Flashlight |
Easy Viewing in the Dark |
|
| EMC EN61326-1 Compliance |
Superior Immunity to Interferences with
Reliable Operations and Readings |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
