| FUNCTION SELECTION |
Toggle Conveniently Between Primary & Secondary Functions |
 |
| SMOOTH MODE |
Smooth Out Unstable Insulation Resistance Readings |
|
| AUTO & MANUAL-RANGING |
Auto-ranging With Manual-ranging Override |
|
ANALOG BAR-GRAPH
|
Fast Update Rate 60/sec |
|
| 6,000 COUNTS WIDE-VIEW LCD DISPLAY |
5/sec Fast Nominal Update Rate |
|
| DUAL DIGITAL DISPLAY |
Simultaneously View Relevant Parameters In Complementary Display |
|
| ASIC TECHNOLOGY |
Allows More Functions & Features At Affordable Prices |
|
| ERGONOMIC STREAMLINE DESIGN |
Fits Comfortably In One's Hand |
|
| RELATIVE ZERO MODE |
For Convenient Readings Comparison And Offset |
|
| LOCK FEATURE |
For Two Handed Continuous Testing Without The Need To Press The TEST Button |
|
| DATA HOLD |
Freezes The Displaying Reading For Later View |
|
| MAX MIN RECORD |
Record Measurement Max & Min Readings |
|
| mA & Hz |
Measures Currents & Frequencies In Dual Display |
|
| INSULATION RESISTANCE TEST |
5 Test Voltages: 50V, 100V, 250V, 500V & 1000V.
It is Useful For Determining The State Of Insulation Material. |
|
| TYPE-K TEMPERATURE |
Measurements -40.0°C To 537.0°C, Selectable °C & °F Readings |
|
| CAPACITANCE |
Autoranging 2.000μF To 20.00mF |
|
| RESISTANCE FUNCTION |
0.01Ω High Resolution, Autoranging 60.00Ω To 60.00MΩ |
|
| TRANSIENT PROTECTION |
Up To 8kV 1.2/50μs Lightning Surge; Superb Protection For Serious Users |
|
| LVD SAFETY |
Meets EN61557-1/-2, & EN61010-1/-2-030/-2-033 CAT III 1kV & CAT IV 600V |
|
| EMC |
Meets EN61326-1: 2013 |
|
| PROTECTIVE HOLSTER |
With Holders For Probe Storage And "third Hand" Feature, Replaceable & Washable |
|
| ACV TRUE RMS 20kHz BANDWIDTH |
For Non-sinusoidal Waveforms Of Complex Voltage Or Current Signals |
|
| INTELLIGENT AUTO-POWER-OFF |
To Extend Battery Life; Awake Resets On Significant Operation & Measurements |
|
| ACCEPTS REMOTE PROBE |
Convenient Activation For Insulation Resistance Tests. Full Silicone Leads To Minimize Insulation Test Error |
|
| BEEP-JACK™ AUDIBLE & VISIBLE WARNING |
Guards Against Improper "- INS. μAmA" & "A" Terminals Plug In. Decreases Risks Of Damage |
|
| VFD V & Hz FEATURE |
Measures Fundamental Voltage & Frequency Of Most Variable Frequency Drives In Dual Display |
|
| Hz OF LINE LEVEL VOLTAGE |
Measures Noisy High Voltage ACV Frequencies In Dual Display |
|
| HIGH IMPEDANCE VOLTAGES |
1000VAC/DC Measuring Capabilities; High Input Impedance For Load Sensitive Circuits |
|
| FAST AUDIBLE CONTINUITY |
For Quick Open-short Tests On Switches, Fuses And Wires |
|
| DIODE TEST |
For Checking Diodes And Rectifiers |
|
| 60.00mV AC/DC RANGES |
0.01mV High Resolution To Test Small Signal Changes |
|
| PAPER-WHITE DISPLAY BACKLIGHT |
For Easy Viewing In The Dark |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
