| FULLY AUTO-RANGING |
Shortens The Time To Measure
And Increases The Ease Of Use |
 |
| MANUAL-RANGING MODE |
Auto-Ranging With
Manual-Ranging Override |
|
| 6000 + 999 COUNTS DUAL DISPLAY |
Simultaneous Measurements
Of ACA+Hz Or ACV+Hz |
|
| 5/S FAST MEASUREMENT |
Display Updates 5 Per Second
Nominal For Fast Changes |
|
| RELATIVE ZERO MODE |
For Convenient Readings
Comparison & Offset |
|
| 5ms CREST-MAX |
Captures Peak Signals Of Volts/
AMPS As Short As 5ms In Duration |
|
| DATA HOLD |
Freezes The Displaying
Reading For Later View |
|
| FULL CURRENT RANGES |
DCA 6 Ranges To 10A, 20A For 30S
ACA 6 Ranges To 10A, 20A For 30S |
|
| AUTO-POWER-OFF |
Extends Battery Life |
|
| TRANSIENT PROTECTION |
Up To 6kV 1.2/50μs Lightning Surge;
More Confidence For Serious Users |
|
| LVD MEASUREMENT CATEGORY |
Meets EN61010-1/-2-030/-2-033
CAT II 1kV, CAT III 600V & CAT IV 300V |
|
| EMC DIRECTIVE |
Meets EN61326-1:2013 |
|
| PROTECTIVE HOLSTER |
Increases Product Durability;
Washable & Replaceable |
|
| RUGGED & DURABLE |
High-Impact Fire-Retarded Enclosure
With Battery Compartment & Access Door |
|
| BEEP-JACK |
Audible & Visible Input Warning
Against Improper Plug In |
|
| VFD V & Hz FEATURE |
Measures Fundamental
Voltage & Frequency Of Most
Variable Frequency Drives |
|
| LINE LEVEL (DUAL DISPLAY) Hz |
Measures Noisy Line Level
Voltage ACV Frequency |
|
| 1kV VOLTAGE MEASUREMENT |
Improved Measuring Capabilities
DCV 5 Auto-Ranges To 1000V
ACV 5 Auto-Ranges To 1000V |
|
| EF-DETECTION |
Both Non-Contact (NCV) &
Single-Probe Voltage Detection
For Identifying Live Lines |
|
| RESISTANCE |
6 Auto-Ranges Up To 60MΩ |
|
| DIODE TEST |
For Testing Diodes & Rectifiers |
|
| CAPACITANCE |
6 Auto-Ranges Up To 3000μF
To Measure Motor Capacitors |
|
| AUDIBLE CONTINUITY |
For Quick Open-Short Tests
On Switches, Fuses And Wires |
|
| LOGIC LEVEL Hz |
Up To 0.001Hz Resolution
Logic Level Frequency |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
