| FUNCTION SELECTION |
Toggle Conveniently Between Primary & Secondary Functions |
 |
| PAPER-WHITE DISPLAY BACKLIGHT |
For Easy Viewing In The Dark |
|
| AUTO & MANUAL-RANGING |
Auto-ranging With Manual-ranging Override |
|
| ANALOG BAR-GRAPH |
Fast Update Rate 60/sec |
|
| 20,000 COUNTS MAX WIDE-VIEW LCD DISPLAY |
5/sec Fast Nominal Update Rate |
|
| DUAL DIGITAL DISPLAY |
Simultaneously View Relevant Parameters In Complementary Display |
|
| ASIC TECHNOLOGY |
Allows More Functions & Features At Affordable Prices |
|
| ERGONOMIC STREAMLINE DESIGN |
Fits Comfortably In One's Hand |
|
| RELATIVE ZERO MODE |
For Convenient Readings Comparison And Offset |
|
| 6,000 / 20,000 COUNTS MODE |
Convenient Selection Of Higher Resolution Vs Higher Decade Limit |
|
| DATA HOLD |
Freezes The Displaying Reading For Later View |
|
| CREST (PEAK HOLD) |
Captures Instantaneous +Peak & -Peak Readings |
|
| HIGH-UPDATE RECORD MAX MIN |
Approx. 2 Times Update Rate To Record Fast Response Max & Min Readings |
|
| μAmA/A +Hz READINGS |
Measures Currents & Frequencies In Dual Display |
|
| CAPACITANCE |
7 Ranges Autoranging, 20.00nF To 20.00mF |
|
| RESISTANCE |
Autoranging 600.0Ω To 60.00MΩ Or 199.99Ω To 19.999MΩ |
|
| TRANSIENT PROTECTION |
Up To 8kV 1.2/50μs Lightning Surge; Superb Protection For Serious Users |
|
| LVD SAFETY |
Meets EN61010-1/-2-030/-2-033 CAT III 1kV & CAT IV 600V |
|
| EMC |
Meets EN61326-1:2013 |
|
| PROTECTIVE HOLSTER |
With Holders For Probe Storage And "Third Hand" Feature, Replaceable & Washable |
|
| ACV TRUE RMS 5kHz BANDWIDTH |
For Non-sinusoidal Waveforms Of Complex Voltage Or Current Signals |
|
| INTELLIGENT AUTO-POWER-OFF |
To Extend Battery Life; Awake Resets On Significant Operation & Measurements |
|
| BEEP-JACK™ AUDIBLE & VISIBLE WARNING |
Guards Against Improper μAmA & A Terminals Plug In. Decreases Risks Of Damage |
|
| VFD V & Hz FEATURE |
Measures Fundamental Voltage & Frequency Of Most Variable Frequency Drives In Dual Display |
|
| Hz Of Line Level Voltage |
Measures Noisy High Voltage ACV Frequencies In Dual Display |
|
| HIGH IMPEDANCE VOLTAGES |
1000VAC/DC Measuring Capabilities; High Input Impedance For Load Sensitive Circuits |
|
| BEEPLIT™ CONTINUITY |
Quick Open-short Tests. Beep and Backlight Effects For Noisy Environments |
|
| DIODE TEST |
For Checking Diodes And Rectifiers |
|
| mV RANGES |
600.0mV Or 199.99mV |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
