| DC+AC & AC 100kHz TRUE RMS |
For Non-sinusoidal & Complex
Waveforms of Volts & Amps.
100kHz High Bandwidth for ACV |
 |
| LINE LEVEL Hz |
Measures Noisy Line Level Voltage
Frequencies |
|
| INNOVATIVE BeepLit™ CONTINUITY |
Quick Open-short Tests on Switches and Wires; Beep + Backlight Effects for Noisy Environments |
|
| FULLY AUTO-RANGING |
Shortens the Time to Measure and
Increases the Ease of Use |
|
| LOGIC LEVEL Hz AND % |
Measures Digital Logic Level Frequencies
and Duty Cycles |
|
| BACKLIGHTED LCD DISPLAY |
For Easy Viewing in The Dark; 16 mins
Auto-Off to Save Battery Power |
|
| 0.03% BASIC DCV ACCURACY |
Measures DCV up to 1000Vdc |
|
| REC MAX MIN AVG READINGS |
Speedy Records Max, Min and Calculates Average Readings Over Time; Automatic APO Disable |
|
| dBm READINGS |
Features 20 Selectable Reference
Impedance Values |
|
| AutoV |
Automatic Selection of ACV or DCV |
|
| LPF ACV & Hz FOR VFDs |
Measures Voltage & Frequency of Most
Variable Frequency Drives and Noisy
Electrical Signals up to 1000Vac |
|
| LoZ GHOST-VOLTAGE-BUSTER |
Low Ramp-up Input Impedance to Drain
Ghost Voltages Leaving Only Hard Signal
Meter Readings |
|
| BEEPJACK™ MIS-INPUT WARNING |
Guards Against Improper Amps Terminals
Plug-in for Voltage Measurements |
|
| RUGGED & DURABLE |
Robust Enclosure; Precise & Reliable Rotary Switch; Premium Plating & Low Leakage PCB |
|
| INTELLIGENT AUTO-POWER-OFF (APO) |
Stays ON While in Measurements;
Intelligently Turns OFF to Extend Battery
Life; Disable option |
|
| EMC |
Superior Immunity to Interferences; Reliable
Operations and Readings; Meets EN61326-1 |
|
| ERGONOMIC & STREAMLINE BODY |
Over-molded Holster Fits Nicely in One
Hand; Reduced Size for Easy Carrying |
|
| RELATIVE ZERO |
REL for Convenient Readings Comparison |
|
| DUAL SENSITIVITIES EF-DETECTION |
Features Non-Contact (NCV) &
Single-Pole Contact Voltage Detections;
Selectable Hi/Lo Dual Sensitivities |
|
| LARGE 60,000 COUNTS LCD DISPLAY |
5-5/6 Digits High Resolution; 5/Sec Fast
Nominal Update Rate |
|
| DATA HOLD |
Freezes the Displaying
Reading for Later View |
|
| FAST ANALOG BAR-GRAPH |
50/Sec Fast Nominal Update Rate |
|
| AUTOHOLD REAL-READ™ |
Shows Real-time Readings and automatically latches the last stable reading for later display |
|
| CREST MAX MIN PEAKS |
Fast Captures +/- Peak Extremes at Durations as Short as 0.25ms; Automatic APO Disable |
|
| %4~20mA READINGS |
Monitors and Verifies Process Control
Loop Currents |
|
| TYPE-K TEMPERATURE |
T1, T2 Dual Inputs; Selectable °C and
°F Readings |
|
| INNOVATIVE BeepLit™ DIODE TEST |
Short-Beep Alert on Forward Voltages
<0.85V; Continuous Beep & Backlight
Effects for Shorted Diode Continuities |
|
| CAPACITANCE |
Up to 10mF for Measuring Motor Capacitors |
|
| LVD CAT III 1000V & CAT IV 600V |
Certified EN61010-2-033, EN61010-1 & Relevant Standards on CAT III 1kV & CAT IV 600V |
|
| nS CONDUCTANCE |
nS=1/GΩ virtually extends Resistance
measurements to the order of GΩ |
|
| TRANSIENT PROTECTION |
Up To 8kV 1.2/50μs Lightning Surge; Fully
Certified by Independent Test Lab; Years of
Credibility for Serious Users |
|
| RESISTANCE |
Best Resolution 0.01Ω At 600Ω Range;
6 Auto-ranges Up To 60MΩ |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
