| LARGE 6000 COUNTS LCD DISPLAY |
5/Sec Fast Nominal Update Rate |
 |
| +/-TRIGGER |
+/-Trigger Polarity For
User-Accustomed Readings |
|
| DATA HOLD |
Freezes The Displaying
Reading For Later View |
|
| ANALOG BAR-GRAPH |
Fast Update Rate 40/Sec |
|
| TRIGGER LEVEL |
4 Sensitivities For More
Variety Of Engine Signals |
|
| AUTO & MANUAL-RANGING |
Auto-Ranging With
Manual-Ranging Override |
|
| TYPE-K TEMPERATURE |
Selectable °C & °F Readings |
|
| mV FUNCTIONS |
0.01mV X-High Resolution
To Cope Better With Most Sensors |
|
| μA/mA/A FUNCTIONS |
Checks Leakage Current
Or Loop Current Consumption |
|
| ERGONOMIC STREAMLINE DESIGN |
Fits Comfortably In One's Hand |
|
| TRANSIENT PROTECTION |
Up To 6kV 1.2/50μs Lightning Surge;
Superb Protection For Serious Users |
|
| LVD SAFETY |
Meets EN61010-1/-2-030/-2-033
CAT II 1kV |
|
| AUTO-POWER-OFF |
To Extend Battery Life |
|
| RUGGED & DURABLE |
High-Impact Fire-Retarded Enclosure
For Reinforced Safety & Durability |
|
| PROTECTIVE HOLSTER |
With Holders For Probe Storage
And "Third Hand" Feature
Replaceable & Washable |
|
| BATTERIES & FUSES ACCESS DOOR |
For Easy Batteries & Fuses
Checking And Replacement |
|
| BEEP-JACK AUDIBLE WARNING |
Beeps Against Improper Amps-Terminal
Plug In. Decreases Risks Of Damage |
|
| RESISTANCE |
Best Resolution 0.1Ω; Auto-Ranging;
Up To 60MΩ With 1000V Protection |
|
| FAST AUDIBLE CONTINUITY |
For Quick Open-Short Tests
On Switches, Fuses, And Wires |
|
| DIODE TEST |
For Checking Diodes
And Rectifiers |
|
| HIGH IMPEDANCE VOLTAGE |
1000VAC/DC Measuring Capabilities;
High Input Impedance For
Load Sensitive Circuits |
|
| Hz OF LINE LEVEL VOLTAGE |
Measures Noisy High Voltage
ACV Frequencies |
|
| IG-RPM READINGS |
Direct RPM Test On Fuel-Injector, Dwell
Or MCU RPM Signals VIA Test Leads |
|
| ms-FUEL INJECTION DETECTOR |
Tests Both TBI & PFI Engines;
User-Selectable Sensitivities |
|
| DWELL-ANGLE & %-DUTY |
Tests Conventional Engines;
User-Selectable Sensitivities |
|
| IP-RPM READINGS |
Inductive Pickup RPM Test On
Spark-Plug Ignition HV Wires |
|
| FUNCTION SELECTION |
Toggle Conveniently Between
Primary & Secondary Functions |
|
| DISPLAY BACKLIGHT |
For Easy Viewing In The Dark |
|
| RPM-4, RPM-2, RPM-2M |
User-Selectable Readings On
4-Stroke, 4-Stroke-DIS / 2-Stroke,
2-Stroke-DIS Engines |
|
| CYLINDER |
Selection Of 1 To 12 Cylinders
For Dwell & IG-RPM Readings |
|
| CAPACITANCE |
Up To 2000μF With 1000V Protection;
Auto-Ranging |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
