| FUNCTION SELECTION |
Toggle Conveniently Between Primary & Secondary Functions |
 |
| WHITE DISPLAY BACKLIGHT |
For Easy Viewing In The Dark |
|
| AUTO & MANUAL-RANGING |
Auto-ranging With Manual-ranging Override |
|
| TRUE RMS MEASUREMENTS |
For Non-sinusoidal Waveforms Of AC Voltages & AC Currents |
|
| LARGE 6000 COUNTS LCD DISPLAY |
5/sec Fast Nominal Update Rate |
|
| MAX MIN AVG RECORD |
Record Max/Min And Calculates Average Readings Over Time |
|
| RELATIVE ZERO MODE |
For Convenient Readings Comparison & Offset |
|
| DATA HOLD |
Freezes The Displaying Reading For Later View |
|
| HI/LO SENSES EF-DETECTION |
Both Non-contact(NCV) & Single-probe Voltage Detection For Identifying Live Lines |
|
| FULL μA, mA & A RANGES |
6 Full Current Ranges With 1000V HBC Fuses Protected |
|
| BEEPLIT™ CONTINUITY |
Quick Open-short Tests. Beep and Backlight Effects For Noisy Environments |
|
| INTELLIGENT AUTO-POWER-OFF |
To Extend Battery Life |
|
| TRANSIENT PROTECTION |
Up To 6kV 1.2/50μs Lightning Surge; Superb Protection For Serious Users |
|
| LVD SAFETY |
Meets EN61010-1/-2-030/-2-033 CAT II 1kV & CAT III 600V |
|
| EMC |
Meets EN61326-1:2013 |
|
| PROTECTIVE HOLSTER |
With Holders For Probe Storage And "Third Hand" Feature, Replaceable & Washable |
|
| BEEP-JACK™ AUDIBLE WARNING |
Beeps Against Improper A-terminal Plug In. Decreases Risks Of Damage |
|
| HIGH IMPEDANCE VOLTAGE |
1000VAC/DC Measuring Capabilities; High Input Impedance For Load Sensitive Circuits |
|
| VFD V & Hz FEATURE |
Measures Fundamental Voltage & Frequency Of Most Variable-Frequency-Drives |
|
| Hz OF LINE LEVEL VOLTAGE |
Measures Noisy High Voltage ACV Frequencies |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
