| Hi/Lo EF-DETECTION |
Both Non-Contact (NCV) &
Single-Probe Voltage Detection
For Identifying Live Lines;
Selectable Hi/Lo Sensitivities |
 |
| ACA 30mm AmpTip™ CLAMP JAWS |
For Large & Small Conductors With
AC TRMS 600A Capability |
|
| DCμA |
For HVAC Flame Sensors
Testing Via Test Probes |
|
| CAPACITANCE |
2 Auto-ranges Up To 2500μF
To Measure Motor Capacitors |
|
| 6000kΩ RESISTANCE |
5 Auto-ranges Up To 6000kΩ
Best Resolution 0.1Ω At 600Ω Range |
|
| ERGONOMIC & STREAMLINE BODY |
Also Comes With A Soft Pouch
For Easy Carrying & Protection |
|
| DUO-CORE MEASUREMENTS |
To Conveniently Measure Amps +
Volts Or Another DMM Function |
|
| DATA HOLD |
Freezes The Displaying
Reading For Later View |
|
| RUGGED & DURABLE |
High-impact Fire-retarded
Enclosure With Battery
Compartment & Access Door |
|
| 1.0% DCV BASIC ACCURACY |
DCV Up To 600V;
ACV Up To 600V |
|
| TRANSIENT PROTECTION |
Up To 6kV 1.2/50μs Lightning Surge;
More Confidence For Serious Users |
|
| EMC |
Meets EN61326-1:2013 |
|
| BACKLIGHTED LCD DISPLAY |
For Easy Viewing In The Dark |
|
| REGULAR CURRENT |
Measures At Jaw Center For
Regular Conductors Up To 600Amps |
|
| AmpTip™ LOW-CURRENTS |
Calibrated To Measure At Jaw Tip For
Small-sized Conductors Up To 60 Amps |
|
| IN-RUSH PEAK-RMS |
Captures In-rush Peak RMS Readings
At Durations As Short As 80ms |
|
| VFD V & Hz FEATURE |
Measures Fundamental
Voltage & Frequency Of Most
Variable Frequency Drives |
|
| FULLY AUTO-RANGING DMM |
Shortens The Time To Measure
And Increases The Ease Of Use |
|
| AUTO-POWER-OFF |
Extends Battery Life |
|
| AUDIBLE + VISIBLE CONTINUITY |
For Quick Open-short Tests
On Switches, Fuses, And Wires;
Visible Flashing Icons |
|
| DIODE TEST |
For Testing Diodes & Rectifiers |
|
| LVD CAT III 600V & CAT IV 300V |
Certified EN61010-2-032, EN61010-2-033,
EN61010-1 & Relevant UL Standards On
CAT III 600V & CAT IV 300V |
|
| TYPE-K TEMPERATURE |
Selectable °C And °F Readings;
Comes With Bkp60 Bead Probe |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
