| 30ms MAX HOLD |
Captures Peak In-Rush Current
As Short As 30ms In Duration |
 |
| DATA HOLD |
Freezes The Displaying
Reading For Later Viewing |
|
| BATTERY COMPARTMENT |
With Access Door For
Easy Battery Replacement |
|
| PROBE HOLDERS |
Built-In Probe Storage Holders |
|
| RELATIVE ZERO MODE |
For Convenient Readings Comparison
& DCA Zero Adjustment |
|
| LARGE EASY-TO-READ LCD DIGITS |
With 3/Sec Nominal Update Rate |
|
| MANUAL-RANGING MODE |
Auto-Ranging With Manual-Ranging Overide |
|
| DIODE TEST |
For Testing Diodes And Rectifiers |
|
| CAPACITANCE |
6 Ranges; Auto-Ranging
Up To 3000μF With 600V Protection |
|
| AUDIBLE CONTINUITY |
For Quick Open-Short Tests
On Switches, Fuses, And Wires |
|
| RESISTANCE |
6 Ranges; Auto-Ranging
Up To 40Mega OHMS With 600V Protection |
|
| TRANSIENT PROTECTION |
Up To 6.5kV 1.2/50μs Lightning Surge;
More Confidence For Serious Users |
|
| EMC |
Meets EN61326(1997, 1998/A1),
EN61000-4-2(1995), & EN61000-4-3(1996) |
|
| AC 800 AMPS MEASUREMENTS |
2 Non-Invasive AC Current Auto-Ranges
VIA Clamp Jaws; Best Resolution 0.1A |
|
| DC 1000 AMPS MEASUREMENTS |
2 Non-Invasive DC Current Auto-Ranges
VIA Clamp Jaws; Best Resolution 0.1A |
|
| 5 FULL AC VOLTAGE RANGES |
From 400mV Range
Up To 600 V Range |
|
| 5 FULL DC VOLTAGE RANGES |
From 400mV Range
Up To 600 V Range |
|
| FUNCTION SELECTION |
Conveniently Toggle Between
Primary & Secondary Functions |
|
| DISPLAY BACKLIGHT |
For Easy Viewing In The Dark |
|
| HIGH SPEED AUTO-RANGING |
Shortens The Time To Test
And Increases The Ease Of Use |
|
| TRUE RMS |
For Non-Sinusoidal Waveforms
Of AC Voltages & AC Currents |
|
| LVD CAT III 600V SAFETY |
Meets EN61010-2-032 CAT III 600V |
|
| RUGGED & DURABLE |
High-Impact Fire-Retarded Enclosure
For Reinforced Safety & Reliability |
|
| LARGE U-SHAPE CLAMP JAWS FOR DCA & ACA |
Measure Currents Of Large Single Conductor
Or Differential Currents Of Multiple Conductors |
|
| STYLISH & HANDY |
Also Comes With A Soft Pouch
For Easy Carrying & Protection |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
