| PATENTED AmpTip™ CLAMP JAWS |
Easy Access & Excellent Repeatability
For Measuring Thin Conductors In Tight Areas |
 |
| LVD CAT III 600V & CAT IV 300V |
Certified EN61010-2-032, EN61010-1 &
Relevant Standards On CAT III 600V &
CAT IV 300V |
|
| REGULAR CURRENT |
Measures At Jaw Center For Regular Conductors Up To 200 Amps |
|
| 0.001A Hi-res AmpTip™ JAWS |
Accurate to Milliamp Levels for Electronic Devices |
|
| 1.0% DCV BASIC ACCURACY |
Measures Up To 600V DC; 60V DC Range Added |
|
| DIRECT LPF ACV & Hz FOR VFD |
Measures Voltage & Frequency Of Most Variable Frequency Drives And Noisy Electrical Signals Up To 600V AC |
|
| BACKLIGHTED LCD DISPLAY |
For Easy Viewing In The Dark |
|
| FULLY AUTO-RANGING |
Shortens The Time To Measure And Increases The Ease Of Use |
|
| INTELLIGENT AUTO-POWER-OFF (APO) |
Stays ON While In Measurements; Intelligently Turns OFF To Extend Battery Life |
|
| ERGONOMIC & STREAMLINE BODY |
Body width <50mm Fits Nicely In A Hand Overall Length <190mm For Easy Carrying |
|
| TRUE RMS MEASUREMENTS |
For Non-sinusoidal & Complex Waveforms Of Voltages & Currents |
|
| RUGGED & DURABLE |
Robust Enclosure; Precise & Reliable Rotary Switch; Premium Plating & Low Leakage PCB |
|
| EMC |
Superior Immunity To Interference; Reliable Operations And Readings; Meets The Latest EN61326-1 |
|
| DUAL SENSITIVITIES EF-DETECTION |
Features Non-Contact (NCV) & Single-Probe Voltage Detection For Identifying Live Lines; Added User Selectable Hi/Lo Sensitivities |
|
| MAX CONDUCTOR SIZE 26mm, 200Amps |
Features 200A AC/DC Hall-effect Jaws with High Resolution Technology |
|
| MAX HOLD |
Update rate is boosted to 40/s to capture surges in the Voltage & Current functions |
|
| INNOVATIVE BeepLit™ DIODE TEST |
Short-Beep Alert On Forward Voltages <0.85V; Beep & Backlight Effects For Shorted Diodes |
|
| RELATIVE ZERO & DC_ZERO |
REL For Convenient Readings Comparison; DC_Zero For DCA Residue Offset |
|
| DATA HOLD |
Freezes The Displaying Reading For Later View |
|
| DCµA |
For HVAC Flame Sensors Testing Via Test Probes |
|
| TYPE-K TEMPERATURE |
Selectable ºC And ºF Readings; Comes With Bkp60 Bead Probe |
|
| CAPACITANCE |
2 Auto-ranges Up To 2500µF To Measure Motor Capacitors |
|
| INNOVATIVE BeepLit™ CONTINUITY |
Quick Open-short Tests On Switches And Wires; Beep & Backlight Effects For Noisy Environments |
|
| RESISTANCE |
Best Resolution 0.1Ω At 600Ω Range; 2 Auto-ranges Up To 6kΩ (BM135ma); 5 Auto-ranges Up To 6000kΩ (BM137ma) |
|
| TRANSIENT PROTECTION |
Up To 6kV 1.2/50µs Lightning Surge; Fully Certified By Independent Test Lab; Years Of Credibility For Serious Users |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
