AUTO-HOLD |
Automatically Captures & Displays
Significant Stable Readings |
|
DATA HOLD |
Freezes The Displaying
Reading For Later View |
|
BATTERY COMPARTMENT |
With Access Door For
Easy Battery Replacement |
|
PROBE HOLDERS |
Built-In Probe Storage Holders |
|
5400 MINUTES Hi-Lo LOGGING |
Logs V Or A Surge (Hi) & SAG (Lo)
Of Every 1 Minute Interval
At Sampling Speed < 50ms |
|
HIGH CURRENT Hz |
Measures Non-Invasive
ACA Frequency VIA Clamp Jaws |
|
HIGH VOLTAGE Hz |
Measures Noisy High Voltage
ACV Frequencies VIA Test Leads |
|
250μs FAST AUDIBLE CONTINUITY |
For Quick Open-Short Tests
On Switches, Fuses, And Wires |
|
RESISTANCE |
Up To 999.9 OHMS, 0.1 OHM
Resolution With 600V Protection |
|
TRANSIENT PROTECTION |
Up To 6.5kV 1.2/50μs Lightning Surge;
More Confidence For Serious Users |
|
EMC |
Meets EN61326(1997, 1998/A1),
EN61000-4-2(1995), & EN61000-4-3(1996) |
|
UP TO AC 1000 AMPS MEASUREMENTS |
3 Non-Invasive AC Current Ranges
VIA Clamp Jaws; Best Resolution 0.01A |
|
TEMPERATURE |
Type-K Measurement;
Selectable °C Or °F Readings;
Comes With BKP60 Bead Probe |
|
0.5% DCV BASIC ACCURACY |
Up To 600 Volts, 0.1V Resolution |
|
DISPLAY BACKLIGHT |
For Easy Viewing In The Dark |
|
WIDE ACV & ACA BAND-WIDTH |
Up To 3.1KHz AC Band-Width
To Measure More True RMS Details |
|
TRUE RMS MEASUREMENTS |
For Non-Sinusoidal Waveforms
Of AC Voltages & AC Currents |
|
PC-COMM INTERFACE CABABILITIES |
Built-In Optical Isolated Data
Output Port. Optional Purchase
Interface Kit For PC Connection |
|
LOGGED DATA RECALL |
Up/Down Quick View Of Hi-Lo Data
On LCD. No Computer Is Required |
|
LVD CAT III 600V SAFETY |
Meets EN61010-2-032 CAT III 600V |
|
RUGGED & DURABLE |
High-Impact Fire-Retarded Enclosure
For Reinforced Safety & Reliability |
|
LARGE U-SHAPE CLAMP JAWS |
Measure ACA Of Large Single Conductor
Or Differential ACA Of Multiple Conductors |
|
STYLISH & HANDY |
Also Comes With A Soft Pouch
For Easy Carrying & Protection |
|
|
Specifications subject to change without notice.
Patented & patents pending. |
|
