| 30ms MAX HOLD |
Captures In-Rush RMS Values Of ACA
Or ACV As Short As 30ms In Duration |
 |
| DATA HOLD |
Freezes The Displaying
Reading For Later View |
|
| LIGHT WEIGHT & SMALL BODY |
Also Comes With A Soft Pouch
For Easy Carrying & Protection |
|
| HIGH VOLTAGE (ACV) Hz |
Measures Noisy High Voltage
ACV Frequency VIA Test Leads |
|
| FAST AUDIBLE CONTINUITY |
For Quick Open-Short Tests
On Switches, Fuses, And Wires |
|
| CAPACITANCE |
6 Auto-Ranges Up To 3000μF
To Measure Motor Capacitors |
|
| DIODE TEST |
For Testing Diodes & Rectifiers |
|
| RESISTANCE |
6 Auto-Ranges Up To 40MΩ
With 600V Protection |
|
| TRANSIENT PROTECTION |
Up To 6kV 1.2/50μs Lightning Surge;
More Confidence For Serious Users |
|
| EMC |
Meets EN61326(1997, 1998/A1),
EN61000-4-2(1995, 2000/A2), & EN61000-4-3(2002) |
|
| μA FUNCTION |
For HVAC Flame Sensors Testing
VIA Test Leads With 600V Protection |
|
| TYPE-K TEMPERATURE |
Selectable °C And °F Readings;
Comes With BKP60 Bead Probe |
|
| 0.5% DCV & ACV BASIC ACCURACY |
DCV 5 Auto-Ranges To 600V;
ACV 4 Auto-Ranges To 600V |
|
| TWIN DISPLAYS |
Simultaneous Measurements Of
A+V, A+OHMS, ...ETC |
|
| FULLY AUTO-RANGING DMM |
Shortens The Time To Measure
And Increases The Ease Of Use |
|
| RUGGED & DURABLE |
High-Impact Fire-Retarded Enclosure
For Reinforced Safety & Reliability |
|
| LVD CAT III 600V SAFETY |
Meets Both EN61010-2-032 CAT III 600V
& UL61010B-2-032 CAT III 600V On All Models |
|
| SMALL & ULTRA-SLIM CLAMP JAWS |
For Easy Access To Tight Places
With AC 600A Capability |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
