| DCμA |
For HVAC Flame Sensors
Testing Via Test Probes |
 |
| PHASE ROTATION |
Dual Sensitivity Modes For
Both Motors And Supply Systems |
|
| CAPACITANCE |
2 Auto-Ranges Up To 2500μF
To Measure Motor Capacitors |
|
| RESISTANCE |
3 Auto-Ranges Up To 60kΩ
Best Resolution 0.1Ω At 600Ω Range |
|
| ERGONOMIC & STREAMLINE BODY |
Also Comes With A Soft Pouch
For Easy Carrying & Protection |
|
| DATA HOLD |
Freezes The Displaying
Reading For Later View |
|
| RELATIVE ZERO & DC_ZERO |
For Convenient Readings Comparison
As Well As DC Jaws Hysteresis Offset |
|
| 0.8% DCV BASIC ACCURACY |
DCV 2 Auto-Ranges To 1000V;
ACV 2 Auto-Ranges To 1000V |
|
| 5ms CREST-MAX |
Captures In-Rush Peak Signals Of ACA
Or ACV As Short As 5ms In Duration |
|
| CONVENIENT Hz BUTTON |
Toggles Between Amps & Hz VIA Jaws,
Or Volts & Hz VIA Test Probes |
|
| RUGGED & DURABLE |
High-Impact Fire-Retarded
Enclosure With Battery
Compartment & Access Door |
|
| TRANSIENT PROTECTION |
Up To 8kV 1.2/50μs Lightning Surge;
More Confidence For Serious Users |
|
| EMC |
Meets EN61326-1:2006(EN55022,
EN61000-3-2/-3 & EN61000-4-2/-3/-4/-5/-6/-8/-11
) |
|
| BACKLIGHTED LCD DISPLAY |
For Easy Viewing In The Dark |
|
| RECORD MAX / MIN / AVG |
Records Max, Min, & Calculates AVG
Readings Over Time. Auto-Ranging |
|
| IN-RUSH PEAK-RMS |
Captures In-Rush Peak RMS Readings
At Durations As Short As 80ms |
|
| AUTO-POWER-OFF |
Extends Battery Life |
|
| FULLY AUTO-RANGING DMM |
Shortens The Time To Measure
And Increases The Ease Of Use |
|
| VFD V & Hz FEATURE |
Measures Fundamental
Voltage & Frequency Of Most
Variable Frequency Drives |
|
| AmpTip LOW-CURRENT & Hz |
Ergonomically Measures At Jaw Tip For
Small-Sized Conductors Up To 60 Amps |
|
| REGULAR CURRENT & Hz |
Measures At Jaw Center For
Regular Conductors Up To 1000 Amps |
|
| FAST AUDIBLE CONTINUITY |
For Quick Open-Short Tests
On Switches, Fuses, And Wires |
|
| DIODE TEST |
For Testing Diodes & Rectifiers |
|
| LVD CAT III 1kV & CAT IV 600V |
Certified EN61010-2-032, EN61010-2-033,
EN61010-1 & Relevant UL Standards On
CAT III 1000V & CAT IV 600V |
|
| AC+DC TRUE RMS MEASUREMENTS |
For Non-Sinusoidal & Complex
Waveforms Of Voltages & Currents |
|
| TYPE-K TEMPERATURE |
Selectable °C And °F Readings;
Comes With Bkp60 Bead Probe |
|
| FLASHLIGHT |
Built-In Convenient Work Light
For Easy Viewing In The Dark |
|
| LARGE 51mm AmpTip CLAMP JAWS |
For Large & Small Conductors With
AC Or DC+AC TRMS 1000A Capability |
|
| EF-DETECTION |
Both Non-Contact (NCV) &
Single-Probe Voltage Detection
For Identifying Live Lines |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
