| 30ms MAX HOLD |
Captures Peak In-Rush Current
As Short As 30ms In Duration |
 |
| DATA HOLD |
Freezes The Displaying
Reading For Later Viewing |
|
| BATTERY COMPARTMENT |
With Access Door For
Easy Battery Replacement |
|
| PROBE HOLDERS |
Built-In Probe Storage Holders |
|
| RELATIVE ZERO MODE |
For Convenient Readings Comparison
& DCA Zero Adjustment |
|
| LARGE EASY-TO-READ LCD DIGITS |
With 3/sec Nominal Update Rate |
|
| HIGH VOLTAGE (ACV) Hz |
Measures Noisy High Voltage
ACV Frequency VIA Test Leads |
|
| DIODE TEST |
For Testing Diodes And Rectifiers |
|
| CAPACITANCE |
6 Ranges; Auto-Ranging
Up To 3000μF With 600V Protection |
|
| AUDIBLE CONTINUITY |
For Quick Open-Short Tests
On Switches, Fuses, And Wires |
|
| RESISTANCE |
6 Ranges; Auto-Ranging
Up To 40Mega OHMS With 600V Protection |
|
| TRANSIENT PROTECTION |
Up To 6.5kV 1.2/50μs Lightning Surge;
More Confidence For Serious Users |
|
| EMC |
Meets EN61326-1:2006
(EN55011, EN61000-3-2/-3 &
EN61010-4-2/-3/-4/-5/-6/-8/-11
) |
|
| AC 400 AMPS MEASUREMENTS |
Non-Invasive AC Current
VIA Clamp Jaws; Best Resolution 0.1A |
|
| DC 400 AMPS MEASUREMENTS |
Non-Invasive DC Current
VIA Clamp Jaws; Best Resolution 0.1A |
|
| TYPE-K TEMPERATURE |
Selectable °C And °F Readings;
Comes With BKP60 Bead Probe |
|
| 5 FULL AC VOLTAGE RANGES |
From 400mV Range
Up To 600 V Range |
|
| 5 FULL DC VOLTAGE RANGES |
From 400mV Range
Up To 600 V Range |
|
| FUNCTION SELECTION |
Conveniently Toggle Between
Primary & Secondary Functions |
|
| HIGH SPEED AUTO-RANGING |
Shortens The Time To Test
And Increases The Ease Of Use |
|
| LVD CAT III 600V SAFETY |
Meets EN61010-1 & EN61010-2-032
2nd Edition CAT III 600V |
|
| RUGGED & DURABLE |
High-Impact Fire-Retarded Enclosure
For Reinforced Safety & Reliability |
|
| SMALL DCA/ACA CLAMP JAWS |
For Easy Access To Tight Places
With 400A DC/AC Capability |
|
| STYLISH & HANDY |
Also Comes With A Soft Pouch
For Easy Carrying & Protection |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
