| DUAL SENSITIVITIES EF-DETECTION |
Features Non-Contact (NCV) & Single-Probe Voltage Detection For Identifying Live Lines; Added User Selectable Hi/Lo Sensitivities |
 |
| MAX CONDUCTOR SIZE 26mm, 600Amps |
Features 600A Extra-slim Jaws ACA Model |
|
| CREST MaxMin IN-RUSH CURRENTS |
Fast Captures In-rush +/- Peak Signals At Durations As Short As 5ms; Automatic APO Disable Feature |
|
| REC MaxMin DISPLAY READINGS |
Records Max & Min Readings Over Time;
Automatic APO Disable Feature |
|
| RELATIVE ZERO |
REL For Convenient Readings Comparison |
|
| DATA HOLD |
Freezes The Displaying Reading For Later View |
|
| INNOVATIVE BeepLit™ DIODE TEST |
Short-Beep Alert On Forward Voltages <0.85V; Beep & Backlight Effects For Shorted Diodes |
|
| INNOVATIVE BeepLit™ CONTINUITY |
Quick Open-short Tests On Switches And Wires; Beep & Backlight Effects For Noisy Environments |
|
| RESISTANCE |
Best Resolution 0.1Ω At 600Ω Range; 2 Auto-ranges Up To 6kΩ |
|
| TRANSIENT PROTECTION |
Up To 6kV 1.2/50µs Lightning Surge; Fully Certified By Independent Test Lab; Years Of Credibility For Serious Users |
|
| PATENTED AmpTip™ CLAMP JAWS |
Easy Access & Excellent Repeatability For Measuring Thin Conductors In Tight Areas |
|
| LVD CAT III 600V & CAT IV 300V |
Certified EN61010-2-032, EN61010-2-033, EN61010-1 & Relevant Standards On CAT III 600V & CAT IV 300V |
|
| REGULAR CURRENT |
Measures At Jaw Center For Regular Conductors Up To 600 Amps |
|
| AmpTip™ LOW-CURRENTS |
Ergonomically Measures At Jaw Tip For Small-sized Thin Conductors Up To 60 Amps |
|
| 1.0% DCV BASIC ACCURACY |
Measures Up To 600V DC |
|
| DIRECT LPF ACV FOR VFD |
Measures Voltage Of Most Variable Frequency Drives And Noisy Electrical Signals Up To 600V AC |
|
| BACKLIGHTED LCD DISPLAY |
For Easy Viewing In The Dark |
|
| FULLY AUTO-RANGING |
Shortens The Time To Measure And Increases The Ease Of Use |
|
| INTELLIGENT AUTO-POWER-OFF (APO) |
Stays ON While In Measurements; Intelligently Turns OFF To Extend Battery Life |
|
| ERGONOMIC & STREAMLINE BODY |
Body width <50mm Fits Nicely In A Hand Overall Length <190mm For Easy Carrying |
|
| TRUE RMS MEASUREMENTS |
For Non-sinusoidal & Complex Waveforms Of Voltages & Currents |
|
| RUGGED & DURABLE |
Robust Enclosure; Precise & Reliable Rotary Switch; Premium Plating & Low Leakage PCB |
|
| EMC |
Superior Immunity To Interference; Reliable Operations And Readings; Meets The Latest EN61326-1 |
|
| |
Specifications subject to change without notice.
Patented & patents pending. |
| |
